Power Distribution Module
PDSX-2
PDSX-2 is a programmable 16-channel automotive power distribution module for motorsport and custom vehicles. It replaces traditional fuse and relay setups with flexible electronic control — cleaner wiring, configurable logic, and CAN bus integration.
16 inputs and 16 outputs for switch and load management.
11 channels up to 10 A and 5 channels up to 20 A.
4 analog inputs with 0–32 V range — each can also be used as a switch input with multiple threshold levels.
12 V / 24 V system support.
User-selectable current limits and cut-off functions per output.
Push button / toggle switch logic with AND / OR / NOT functions.
Each input can be controlled by a physical switch, CAN bus, or both simultaneously.
CAN bus control with freely selectable ON/OFF/FAULT status messaging.
Multiple units can be connected via CAN bus if more outputs are needed.
Bluetooth, USB and CAN for data transfer and configuration.
USB PC interface for configuration and firmware updates.
High quality enclosures and connectors — supplied with connectors and pins.
756.17 € (VAT 0%, outside EU) / 949.00 € (incl. VAT 25.5%, EU)
Documentation
